GALVANIZED WIRE

    GALVANIZED WIRE

    Our company has moved to a new facility and continues production with three production lines. At our new facility, we have three fully automatic galvanizing lines with a production capacity of 30 wires per line and 8,000 tons per month. The second and third production lines provide homogeneous annealing with the advantage of the fluidized bed system and the aluminum quartz sand side of the furnace that contacts all the surfaces of the wires. This kind of oven we use has the latest technology and all the equipment is imported from Canada.

    Our production lines can produce commercial coated and coated wires, profile, strip and plaque from 0.80 mm to 8.00 mm thick. Commercial coated wires are produced with a pad wiping system with a high quality and coating and surface of the wires. High-Zinc coated wires are produced with a nitrogen wiping system. Production with low or medium carbon level, which is in international standards, is available in our production. Our wires are produced with 38-48-50 mm inner diameter and 70-80-95 mm outer diameter rosette cooling system. Column weights can vary between 350 kg and 2000 kg.

    Raw Material Standards Wire Diameter Coating Amount Coating Type Tensile Strength Coil Weight Coil Inner Diameter Coil Outside Diameter
    SAE-1006, SAE-1008, SAE-1010 etc. 0.80 - 10.00 mm 30 - 600 gr/m2 Hot-Dip Galvanizing 400 - 1000 N/mm2 50 - 1500 kg 350, 450, 550 mm 650, 750, 850, 1100 mm

    Final Product Standarts:

    TS-EN-10244, BS-443, DIN-1548, ASTM-A-475

    Area of Usage:

    Spiral braided fence wires, industirial purposes, enviromental security systems, agriculture, forestry and animal husbandry, automotive etc…

    Please contact us for more detailed technical information...
